• Interfacing TraCI from Python

The TraCI commands are split into thedomains busstop, calibrator, chargingstation, edge, gui, inductionloop, junction, lane,lanearea, meandata, multientryexit, overheadwire, parkingarea, person, poi, polygon,rerouter, route, routeprobe, simulation, trafficlight, variablespeedsign, vehicle, and vehicletype,vehicle, which correspond to individual modules. For a detailed list ofavailable functions see the pydoc generated documentation. The source codecan be found at[1].

Please note that if performance is an issue and you don't a need GUI, it is almost always betterto use libsumo instead of traci, which has the same API.

importing traci in a script#

To use the library, you can install it using pip install traci or add the <SUMO_HOME>/tools directoryto your Python load path. This is typically done with a stanza like this:

import osimport sysif 'SUMO_HOME' in os.environ: sys.path.append(os.path.join(os.environ['SUMO_HOME'], 'tools'))import traci

This assumes that the environment variableSUMO_HOMEis set before running the script. Alternatively, you can declare thepath to sumo/tools directly as in the line

sys.path.append(os.path.join('c:', os.sep, 'whatever', 'path', 'to', 'sumo', 'tools'))

If you decide to switch to libsumo at a later stage or want to be flexible here,you can replace the import line later by:

import libsumo as traci

First Steps#

In general it is very easy to interface with SUMO from Python (thefollowing example is a modification oftutorial/traci_tls):

First you compose the command line to start eithersumo or sumo-gui (leaving outthe option which was needed before 0.28.0):

sumoBinary = "/path/to/sumo-gui"sumoCmd = [sumoBinary, "-c", "yourConfiguration.sumocfg"]

Then you start the simulation and connect to it with your script:

import tracitraci.start(sumoCmd)step = 0while step < 1000: traci.simulationStep() if traci.inductionloop.getLastStepVehicleNumber("0") > 0: traci.trafficlight.setRedYellowGreenState("0", "GrGr") step += 1traci.close()

After connecting to the simulation, you can emit various commands andexecute simulation steps until you want to finish by closing theconnection. By default, the close command will wait until the sumoprocess really finishes. You can disable this by calling:

traci.close(False)

Subscriptions#

Subscriptions can be thought of as a batch mode for retrievingvariables. Instead of asking for the same variables over and over again,you can retrieve the values of interest automatically after each timestep. TraCI subscriptions are handled on a per module basis. That is youcan ask the module for the result of all current subscriptions aftereach time step. In order to subscribe for variables you need to knowtheir variable ids which can be looked up in the traci/constants.pyfile.

import traciimport traci.constants as tctraci.start(["sumo", "-c", "my.sumocfg"])traci.vehicle.subscribe(vehID, (tc.VAR_ROAD_ID, tc.VAR_LANEPOSITION))print(traci.vehicle.getSubscriptionResults(vehID))for step in range(3): print("step", step) traci.simulationStep() print(traci.vehicle.getSubscriptionResults(vehID))traci.close()

The values retrieved are always the ones from the last time step, it isnot possible to retrieve older values.

Context Subscriptions#

Context subscriptions work like subscriptions in that they retrieve alist of variables automatically for every simulation stop. However, thedo so by setting a reference object and a range and then retrievingvariables for all objects of a given type within range of the referenceobject.

TraCI context subscriptions are handled on a per module basis. That isyou can ask the module for the result of all current subscriptions aftereach time step. In order to subscribe for variables you need to thedomain id of the objects that shall be retrieved and the variable idswhich can be looked up in the traci/constants.py file. The domain idalways has the form CMD_GET_<DOMAIN>_VARIABLE. The following coderetrieves all vehicle speeds and waiting times within range (42m) of ajunction (the vehicle ids are retrieved implicitly).

import traciimport traci.constants as tctraci.start(["sumo", "-c", "my.sumocfg"])traci.junction.subscribeContext(junctionID, tc.CMD_GET_VEHICLE_VARIABLE, 42, [tc.VAR_SPEED, tc.VAR_WAITING_TIME])print(traci.junction.getContextSubscriptionResults(junctionID))for step in range(3): print("step", step) traci.simulationStep() print(traci.junction.getContextSubscriptionResults(junctionID))traci.close()

The values retrieved are always the ones from the last time step, it isnot possible to retrieve older values.

Context Subscription Filters#

For vehicle-to-vehicle context subscriptions (i.e., contextsubscriptions, whose reference object is a vehicle and whose requestedcontext objects are vehicles as well) it is possible to requestadditional filters to be applied already on the server side. The generalprocedure is to equip a requested context subscription with the filterdirectly after the call to subscribeContext() by a successive call toaddSubscriptionFilter<FILTER_ID>() as for instance in the followingsnippet:

traci.vehicle.subscribeContext("ego", tc.CMD_GET_VEHICLE_VARIABLE, 0.0, [tc.VAR_SPEED])traci.vehicle.addSubscriptionFilterLanes(lanes, noOpposite=True, downstreamDist=100, upstreamDist=50)

The first line requests a context subscription for the speed of vehiclesin the neighborhood of the reference vehicle with the ID "ego". Therange of the context subscription (which refers to the radial contextregion of the usual subscription mechanism) can be set equal to 0.0,since it is be overridden by the selective values of downstreamDistand upstreamDist, respectively, given to the call ofaddSubscriptionFilterLanes() in the second line. The call toaddSubscriptionFilter<FILTER_NAME>() automatically takes effect onthe last issued context subscription, which has to be of thevehicle-to-vehicle form for a successful application.

The following filter types are available:

• Lanes: Return surrounding vehicles on lanes specified relatively to the reference vehicle
• CFManeuver: Return leader and follower on the reference vehicle's lane
• LCManeuver: Return leader and follower on the reference vehicle's lane and neighboring lane(s)
• Turn: Return conflicting vehicles on upcoming junctions along the vehicle's route
• VType: Only return vehicles of the specified vTypes
• VClass: Only return vehicles of the specified vClasses

See the pydocdocumentationfor detailed specifications.

Adding a StepListener#

Often a function needs to be called each time whentraci.simulationStep() is called, to let this happen automatically(always after each call to simulationStep()) it is possible to add aStepListener object 'listener' (more precisely an instance of a subclassof traci.StepListener) i.e.

class ExampleListener(traci.StepListener): def step(self, t): # do something after every call to simulationStep print("ExampleListener called with parameter %s." % t) # indicate that the step listener should stay active in the next step return Truelistener = ExampleListener()traci.addStepListener(listener)

Please note that the listener is not activated for every simulation stepbut for every call to simulationStep (which may perform multiple steps up to the given time t).Furthermore the parameter t is not the current simulation time but exactlythe (optional) parameter passed to the simulationStep call (which is 0 by default).

Controlling parallel simulations from the same TraCI script#

The TraCI python library can be used to control multiple simulations atthe same time with a single script. The function traci.start() has anoptional label argument which allows you to call it multiple times withdifferent simulation instances and labels. The function traci.switch()can then be used to switch to any of the initialized labels:

traci.start(["sumo", "-c", "sim1.sumocfg"], label="sim1")traci.start(["sumo", "-c", "sim2.sumocfg"], label="sim2")traci.switch("sim1")traci.simulationStep() # run 1 step for sim1traci.switch("sim2")traci.simulationStep() # run 1 step for sim2traci.switch("sim1")traci.close()traci.switch("sim2")traci.close()

If you prefer a more object oriented approach you can also useconnection objects to communicate with the simulation. They have thesame interface as the static traci. calls but you will still need tostart the simulation manually for them:

traci.start(["sumo", "-c", "sim1.sumocfg"], label="sim1")traci.start(["sumo", "-c", "sim2.sumocfg"], label="sim2")conn1 = traci.getConnection("sim1")conn2 = traci.getConnection("sim2")conn1.simulationStep() # run 1 step for sim1conn2.simulationStep() # run 1 step for sim2

Controlling the same simulation from multiple clients#

To connect with multiple clients, the number of clients must be known inadvance and specified with sumo option --num-clients <INT>. Also, the connection port mustbe known to all clients. After deciding on a port it can be madeavailable to the clients via arguments or configuration files. A freeport can be obtained by

from sumolib.miscutils import getFreeSocketPortport = sumolib.miscutils.getFreeSocketPort()

One client may use method traci.start() to start the simulation andconnect to it at the same time while the other client only needs toconnect. After establishing client order, each client must continuouslycall simulationStep to allow the simulation to advance:

#client1# PORT = int(sys.argv[1]) # exampletraci.start(["sumo", "-c", "sim.sumocfg", "--num-clients", "2"], port=PORT)traci.setOrder(1) # number can be anythingwhile traci.simulation.getMinExpectedNumber() > 0: traci.simulationStep() # more traci commandstraci.close()

# client2# PORT = int(sys.argv[1]) # exampletraci.init(PORT)traci.setOrder(2) # number can be anything as long as each client gets its own numberwhile traci.simulation.getMinExpectedNumber() > 0: traci.simulationStep() # more traci commandstraci.close()

Concurrent access to the same TraCI connection#

Before SUMO 1.17.0 the pure Python client as well as the libtraci implementationwill probably crash if you try to access the same connection from differentthreads.

Currently there are some measures implemented which at least prevent the directconflicts when accessing the socket. It is however still encouraged to use themulti-client approach from the previous section. It is the only way to ensurethat commands are sent in the expected order. If there is only one thread issuingthe simulationStep command and the others only querythe simulation also multi threaded access should work.

Additional Functions#

When using TraCI there are some common tasks which are not covered bythe traci library such as

• Analyzing the road network
• Parsing simulation outputs

For this functionality it is recommended to useTools/Sumolib

Pitfalls and Solutions#

• Note that strings, if exchanged, had to be plain ASCII before 1.18.0. Currently UTF-8 should be possible for all the strings.
• If you start sumo from within your python script using subprocess.Popen, be sure to call wait() on the resulting process object before quitting your script. You might loose output otherwise.

Determine the traci library being loaded#

When working with different sumo versions it may happen that the call import traci loads the wrong library.The easiest way to debug this is to add the following lines after the import

import traciprint("LOADPATH:", '\n'.join(sys.path))print("TRACIPATH:", traci.__file__)sys.exit()

Make sure that the TRACIPATH corresponds to the sumo version that you wish to use.If it does not, then the order of directories in LOADPATH (sys.path) must be changedor the SUMO installation must be removed from any directories that come before the wanted directory.

Debugging a TraCI session on Linux#

Sometimes SUMO may crash while running a simulation with TraCI. Thebelow steps make it simple to run sumo with traci in a debugger:

1) Add the option --save-configuration to your traci script:

traci.start([sumoBinary, '-c', 'run.sumocfg', '--save-configuration', 'debug.sumocfg'])

2) Run your traci script. Instead of starting sumo it will just writethe configuration with the chosen port but it will still try to connectrepeatedly.

3) Run

gdb --args sumoD -c debug.sumocfg

(where sumoD is sumo compiled in debugmode)

Generating a log of all traci commands#

To share a traci scenario (i.e. in a bug report) it may be useful to separate the logic of the traci script from the actual commands.For this, the function traci.start accepts the optional arguments traceFile and traceGetters.When calling traci.start([<commands>], traceFile=<LOG_FILE_PATH>) all traci commands that were sent to sumo will be written to the given LOG_FILE_PATH.This allows re-running the scenario without the original runner script.

When option traceGetters=False is set, only functions that change the simulation state are included in the log file. Functions that retrieve simulation data are technically not needed to reproduce a scenario but it may be useful to include them if the data retrieval functions are themselves the cause of a bug.

When option traceGetters="print" is set, all getter functions will print themselves and their results to standard output when running the log as a python program.

Determine why the TraCI client cannot connect#

Possibly, the arguments given to traci.start generated an error when launching SUMO. This will manifest as

traci.exceptions.FatalTraCIError: Could not connect.

To diagnose the problem, add options for writing a log file traci.start (i.e. traci.start(['sumo', '-c', 'example.sumocfg', '--log', 'logfile.txt']))After the script fails to start, look into the written logfile and fix the error reported therein.

Usage Examples#

Run a simulation until all vehicles have arrived#

while traci.simulation.getMinExpectedNumber() > 0: traci.simulationStep()

Add trips (incomplete routes) dynamically#

Define a route that consists of the start and destination edge:

traci.route.add("trip", ["startEdge", "endEdge"])

Then add the vehicle with that route

traci.vehicle.add("newVeh", "trip", typeID="reroutingType")

This will cause the vehicle to compute a new route from startEdge toendEdge according to the estimated travel times in the network at thetime of departure. For details of this mechanism seeDemand/Automatic_Routing.

Coordinate transformations#

x, y = traci.vehicle.getPosition(vehID)lon, lat = traci.simulation.convertGeo(x, y)x2, y2 = traci.simulation.convertGeo(lon, lat, fromGeo=True)

edgeID, lanePosition, laneIndex = traci.simulation.convertRoad(x3, y3)edgeID, lanePosition, laneIndex = traci.simulation.convertRoad(lon2, lat2, True)

Retrieve the timeLoss for all vehicles currently in the network#

import traciimport traci.constants as tctraci.start(["sumo", "-c", "my.sumocfg"])# pick an arbitrary junctionjunctionID = traci.junction.getIDList()[0]# subscribe around that junction with a sufficiently large# radius to retrieve the speeds of all vehicles in every steptraci.junction.subscribeContext( junctionID, tc.CMD_GET_VEHICLE_VARIABLE, 1000000, [tc.VAR_SPEED, tc.VAR_ALLOWED_SPEED])stepLength = traci.simulation.getDeltaT()while traci.simulation.getMinExpectedNumber() > 0: traci.simulationStep() scResults = traci.junction.getContextSubscriptionResults(junctionID) halting = 0 if scResults: relSpeeds = [d[tc.VAR_SPEED] / d[tc.VAR_ALLOWED_SPEED] for d in scResults.values()] # compute values corresponding to summary-output running = len(relSpeeds) halting = len([1 for d in scResults.values() if d[tc.VAR_SPEED] < 0.1]) meanSpeedRelative = sum(relSpeeds) / running timeLoss = (1 - meanSpeedRelative) * running * stepLength print(traci.simulation.getTime(), timeLoss, halting)traci.close()

Handling Exceptions#

Sometimes commands raise an (recoverable) exception to indicate an error (unknown id, route not found etc.). These exceptionscan be handled by your code as follows:

try: pos = traci.vehicle.getPosition(vehID)except traci.TraCIException: pass # or do something smarter

Further Resources#

• The module Simpla provides a library for platooning functions that can be integrated with user client scripts.
